LPS25HConfig Struct Reference

LPS25H configuration structure. More...

#include <lps25h.h>

Collaboration diagram for LPS25HConfig:

Data Fields
SPIDriver *	spip
	SPI driver associated to this LPS25H. More...
const SPIConfig *	spicfg
	SPI configuration associated to this LPS25H. More...
I2CDriver *	i2cp
	I2C driver associated to this LPS25H. More...
const I2CConfig *	i2ccfg
	I2C configuration associated to this LPS25H. More...
lps25h_sad_t	slaveaddress
	LPS25H slave address. More...
float *	barosensitivity
	LPS25H barometer subsystem initial sensitivity. More...
float *	barobias
	LPS25H barometer subsystem initial bias. More...
float *	thermosensitivity
	LPS25H thermometer subsystem initial sensitivity. More...
float *	thermobias
	LPS25H thermometer subsystem initial bias. More...
lps25h_odr_t	outputdatarate
	LPS25H output data rate selection. More...
lps25h_bdu_t	blockdataupdate
	LPS25H block data update. More...
lps25h_avgp_t	baroresolution
	LPS25H barometer subsystem resolution. More...
lps25h_avgt_t	thermoresolution
	LPS25H thermometer subsystem resolution. More...

Detailed Description

LPS25H configuration structure.

Definition at line 364 of file lps25h.h.

Field Documentation

SPIDriver* LPS25HConfig::spip

SPI driver associated to this LPS25H.

Definition at line 370 of file lps25h.h.

const SPIConfig* LPS25HConfig::spicfg

SPI configuration associated to this LPS25H.

Definition at line 374 of file lps25h.h.

I2CDriver* LPS25HConfig::i2cp

I2C driver associated to this LPS25H.

Definition at line 380 of file lps25h.h.

Referenced by lps25hStart().

const I2CConfig* LPS25HConfig::i2ccfg

I2C configuration associated to this LPS25H.

Definition at line 384 of file lps25h.h.

lps25h_sad_t LPS25HConfig::slaveaddress

LPS25H slave address.

Definition at line 388 of file lps25h.h.

float* LPS25HConfig::barosensitivity

LPS25H barometer subsystem initial sensitivity.

Definition at line 393 of file lps25h.h.

float* LPS25HConfig::barobias

LPS25H barometer subsystem initial bias.

Definition at line 397 of file lps25h.h.

float* LPS25HConfig::thermosensitivity

LPS25H thermometer subsystem initial sensitivity.

Definition at line 401 of file lps25h.h.

float* LPS25HConfig::thermobias

LPS25H thermometer subsystem initial bias.

Definition at line 405 of file lps25h.h.

lps25h_odr_t LPS25HConfig::outputdatarate

LPS25H output data rate selection.

Definition at line 409 of file lps25h.h.

lps25h_bdu_t LPS25HConfig::blockdataupdate

LPS25H block data update.

Definition at line 414 of file lps25h.h.

lps25h_avgp_t LPS25HConfig::baroresolution

LPS25H barometer subsystem resolution.

Definition at line 418 of file lps25h.h.

lps25h_avgt_t LPS25HConfig::thermoresolution

LPS25H thermometer subsystem resolution.

Definition at line 422 of file lps25h.h.
